N301M | Bronze Pedestal Flexible Impeller Pump

Bronze Construction:
The pump's body is made from high-quality bronze, offering excellent resistance to corrosion and wear. This ensures a longer lifespan and reliable performance in harsh environments.

Large Suction and Discharge Ports:
These ports facilitate efficient fluid transfer, minimizing flow restrictions and enhancing overall pump performance.

Teflon® Barrier Seals:
These seals protect the ball bearings from contaminants, significantly extending the pump's operational life by preventing premature wear and tear.

Mechanical Carbon Ring and Ceramic Face Main Pump Seal:
This standard seal configuration provides robust sealing capabilities, ensuring leak-free operation. An optional Buna N lip seal is available for specific applications.

Sealed Ball Bearings:
The pump features two sealed ball bearings spaced to maximize load capacity, ensuring smooth and efficient operation under various conditions.

Large Vent and Drain Openings:
These openings separate the seal and bearing areas, preventing contamination and facilitating easy maintenance.

Shaft Slinger:
This feature provides additional protection for the bearings, further enhancing the pump's durability.

Neoprene Impeller:
The standard impeller material is neoprene, known for its flexibility and durability. An optional Buna N impeller is available for applications involving oil-contaminated water or kerosene.

High Chrome Nickel Stainless Steel Shaft:
This shaft material offers exceptional strength and resistance to corrosion, ensuring reliable performance over time.

Easy Maintenance:
The impeller and cam are designed for easy replacement, reducing downtime and maintenance costs.

Buna N O-ring:
This O-ring eliminates gasket problems, providing a secure and reliable seal between the pump body and cover.

Machined-in Cam:
This feature reduces impeller wear, enhancing the pump's efficiency and extending its service life.
