Bronze Pedestal Gear Pump - N13HD

Features:

• All Bronze Castings and Stainless Steel Shafts:
  The N13HD is constructed with top-quality bronze and 303 stainless steel shafts, making it a highly durable gear pump that resists corrosion and wear.
• Self-Lubricating Carbon Bearings:
  Equipped with carbon-graphite bearings, this pump boasts self-lubricating properties, reducing the need for frequent maintenance and enhancing operational longevity.
• Electric Clutch Options:
  For applications requiring precise control, the N13HD offers optional gear pump electric clutch configurations, providing versatility and ease of use.

Performance:

Drive & Alignment:
The N13HD functions optimally as a direct drive gear pump, though it can also be configured for belt drive systems. Proper gear pump alignment is vital for achieving satisfactory pump life and should be checked after installation.

Noise:
Recognizing the importance of a low-noise gear pump, the N13HD has been designed to minimize operational sound, making it suitable for installation in quieter workspaces.

Suction Lift:

High Suction Lift Gear Pump:
This pump is capable of impressive suction lift, reaching up to 20 feet (6 m), categorizing it as a high suction lift gear pump that can handle challenging fluid transfer tasks with ease.

Self-Priming Gear Pump:
The N13HD is also self-priming, adding to its reliability and ease of operation, although the use of a gear pump foot valve is recommended to ensure peak performance.

For those who require a pump that can handle high-temperature liquids, the N13HD is an excellent choice. Its construction allows it to function effectively as a gear pump for high-temperature liquids, while also being abrasion resistant and suitable for clean liquid applications.
